10653. XOR Sum



The tree with n vertices is given. The edges of the tree have  weights of only 0 or 1. Let’s find the XOR sum between all pairs of vertices. Compute the sum of all XOR sums.



Input. The first line contains the number of vertices n (2 ≤ n ≤ 105) in the graph. The next n – 1 lines describe the edges. Each line contains three integers: the numbers of the vertices connected by the edge (vertices are numbered from 1 to n) and the weight of the edge (0 or 1).



Output. Print the sum of XOR sums between all pairs of vertices.



Sample input

Sample output

5

1 2 1

2 3 1

2 4 0

4 5 1

6





SOLUTION

graphs – depth first search



Algorithm analysis

Using depth-first search, compute the XOR sum between vertex 1 and all other vertices. Store the XOR sum between vertex 1 and v in x[v]. Let ones be the number of ones and zeroes be the number of zeros in the array x (ones + zeroes = n). Then the answer to the problem will be ones * zeroes.



Example

Consider the graph provided in the example.

Next to each vertex v, the XOR sum x[v] between 1 and v is written. If x[v] = x[u] for some vertices v and u, then the XOR sum between them is equal to 0, thus contributing 0 to the total sum. The XOR sum for each pair of vertices (v, u), for which x[v] ≠ x[u], contributes 1 to the total sum.

Therefore, the answer is equal to the number of pairs of vertices (v, u) for which x[v] ≠ x[u]. This number is equal to ones * zeroes = 2 * 3 = 6. The pairs of vertices that contribute 1 to the total sum are: (1, 2), (1, 4), (2, 3), (2, 5), (3, 4), (4, 5).



Algorithm implementation

Store the input graph in the adjacency list g. Declare an array x.



vector<vector<pair<int,int> > > g;

vector<int> x;



The dfs function implements a depth-first search that computes the XOR sum x[v] between vertices 1 and v. The current XOR sum between 1 and v is represented by cur_xor. The parent of vertex v is p.



void dfs(int v, int cur_xor, int p = -1)

{

  x[v] = cur_xor;

  for (auto z : g[v])

  {

    int to = z.first;

    int w = z.second;

    if (to != p) dfs(to, cur_xor ^ w, v);

  }

}



The main part of the program. Read the input graph.



scanf("%d", &n);

g.resize(n + 1);

x.resize(n + 1);



for (i = 1; i < n; i++)

{

  scanf("%d %d %d", &u, &v, &d);

  g[u].push_back({v, d});

  g[v].push_back({u, d});

}



Start the depth-first search from vertex 1.



dfs(1, 0, -1);



Compute the number of zeroes and ones in the array x.



ones = 0;

for (i = 1; i <= n; i++)

  if (x[i] == 1) ones++;

zeroes = n - ones;



Print the answer.



printf("%lld\n", 1LL * ones * zeroes);



Python implementation

The dfs function implements a depth-first search that computes the XOR sum x[v] between vertices 1 and v. The current XOR sum between 1 and v is represented by cur_xor. The parent of vertex v is p.



def dfs(v, cur_xor = 0, p = -1):

  x[v] = cur_xor

  for to, w in g[v]:

    if to != p:

      dfs(to, cur_xor ^ w, v)



The main part of the program. Read the input graph.



n = int(input())

g = [[] for _ in range(n + 1)]

for _ in range(n - 1):

  u, v, d = map(int, input().split())

  g[u].append((v, d))

  g[v].append((u, d))



Initialize the list x.



x = [0] * (n + 1)



Start the depth-first search from vertex 1.



dfs(1)



Compute the number of zeroes and ones in the list x.



ones = sum(x)

zeroes = n – ones



Print the answer.



print(ones * zeroes)
